Flag of North Korea
Author:
Senan Sekhon
Last Updated:
há 3 anos
License:
Creative Commons CC BY 4.0
Abstract:
Flag of the Democratic People's Republic of Korea
\begin
Discover why 18 million people worldwide trust Overleaf with their work.
\begin
Discover why 18 million people worldwide trust Overleaf with their work.
\documentclass[10pt]{article}
%This is the minimal setup required to render the flag
\usepackage[paperwidth=144cm, paperheight=72cm, top=0cm, bottom=0cm, left=0cm, right=0cm]{geometry}
%Paper width is set to 144cm by 72cm to match the DPRK Government-specified aspect ratio (2:1)
\usepackage{tikz}
%\usepackage[dvipsnames]{xcolor} % Optional unless you want to use colors pre-defined by the xcolor package
% DPRK Government-specified colors for the flag
\definecolor{dprkred}{HTML}{ED1C27}
\definecolor{dprkblue}{HTML}{024FA2}
\definecolor{dprkwhite}{HTML}{FFFFFF}
% Other government specifications include:
% Blue stripe width is 1/12 flag width, here it is 12cm
% White stripe width is 1/72 flag width, here it is 2cm
% Red stripe width is 11/36 flag width, here it is 44cm
% Center of star (and circle) is 1/3 flag width (here it is 48cm) from left edge of flag
% Diameter of circle is 2/9 flag width, here it is 32cm
% Diameter of star is 31/144 flag width, here it is 31cm
%Source: https://commons.wikimedia.org/wiki/File:Flag_of_North_Korea_(Construction_sheet).svg
%Created by Senan Sekhon, August 5, 2021
\begin{document}
\begin{center} %Optional, but helps to tidy up the layout
\begin{tikzpicture}[scale=1] %Scale must be changed to make the flag fit on letter/A4 paper (scale=1 produces a 144cm by 72cm flag)
\clip (-72,-36) rectangle (72,36); %Optional, crops the flag to the correct size
\draw[-] (-72,-36) rectangle (72,36); %Optional, draws a border around the flag
\fill[dprkblue] (-72,24) rectangle (72,36); %Top blue stripe
\fill[dprkwhite] (-72,22) rectangle (72,24); %Top white stripe
\fill[dprkred] (-72,-22) rectangle (72,22); %Red stripe
\fill[dprkwhite] (-72,-24) rectangle (72,-22); %Bottom white stripe
\fill[dprkblue] (-72,-36) rectangle (72,-24); %Bottom blue stripe
\begin{scope}[shift={(-24,0)}] %Circle and star
\fill[dprkwhite] (0,0) circle (16); %White circle
\fill[dprkred] (90:31/2)--(54:{31/4*(3-sqrt(5))})--(18:31/2)--(-18:{31/4*(3-sqrt(5))})--(-54:31/2)--(-90:{31/4*(3-sqrt(5))})--(-126:31/2)--(-162:{31/4*(3-sqrt(5))})--(-198:31/2)--(-234:{31/4*(3-sqrt(5))})--cycle; %Red star
\end{scope}
\end{tikzpicture}
\end{center}
\end{document}
